RFJ Low Temperature For V Type Box Refrigeration Condensing Units Compressed

RFJ Low Temperature For V Type Box Refrigeration Condensing Units Compressed
RFJ Low Temperature For V Type Box Refrigeration Condensing Units Compressed RFJ Low Temperature For V Type Box Refrigeration Condensing Units Compressed RFJ Low Temperature For V Type Box Refrigeration Condensing Units Compressed RFJ Low Temperature For V Type Box Refrigeration Condensing Units Compressed

تصویر بزرگ :  RFJ Low Temperature For V Type Box Refrigeration Condensing Units Compressed

جزئیات محصول:
Place of Origin: SHENZHEN China
نام تجاری: RFJ Brand
گواهی: CE
Model Number: 6HE-28Y
پرداخت:
Minimum Order Quantity: 1 piece
قیمت: discussed
Packaging Details: standard wooden packaging
Delivery Time: 15-20 days
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 1000pices/year
توضیحات محصول جزئیات
Type:: Air-Cooled Cooling Water:: Industrial Water
Type: System Type Fans Species: Frequency Fan
Noise Level:: Low Application Fields: Cooling System
گواهی: RoHS, ISO, CE Condition: New
Heat Transfer Area: 75 Sq Meter Heat Transfer Capacity: 21.4kw
Total Air Volume: 2*3400CMH Rows*Tubes: 5*14
HS Code: 8418692090
برجسته:

,

,

bitzer condenser unit

Product Description



RFJ Low Temperature For V Type Box Compressed Condenser Unit

type box compressed condenser unit
Components:
(1) Condensing unit: , Copeland, Maneurop, Fusheng, , Taikang
(2) Evaporator: KELTESS air-cooler.
(3) Insulation Panel: PU, EPS.
(4) Other accessories: world-famous brands, like , Castle, Every Control, Siemens, LG

RFJ Low Temperature For V Type Box Refrigeration Condensing Units Compressed 0

Walk In Cooler Box,Walk In Cooler,Cooler box Application
1.Vegetable, Fruit Storage Cooler (0-5'C)
2.Drinks, Beer Walk in Cooler (2-8'C)
3.Meat, Fish Storage Freezer (-18'C)
4.Medicine Storage Cooler (2-8'C)
5.Medicine Storage Freezer (-20'C)
6.Meat, Fish Blast Freezer (-35'C)

Application: Food(meat, vegetable, fruit, dairy, drink), medicine, chemical, electronics, etc.
-- materials: Polyurethane and metal sheet. Metal sheet: It is can be with painted steel sheet and stainless steel sheet for choice.
-- with electric heating wire around doorframe to void icing.
-- safe doorknob inside..
-- positive plastic seal fixed to door to avoid cooling air losses.,

RFJ Low Temperature For V Type Box Refrigeration Condensing Units Compressed 1

specification:
1.Copeland scroll Compressor.
2.Hi-thread condenser.
3.High-thread series of low-temperature DL evaporator
4. high-end expansion valve. (Series expansion valve fot freezer, capillary cut for cooler)
5.Full computer control system (automatic control).
6.Apan Saginomiya/ Shangheng solenoid valve (a set of solenoid valve has two units for high temperature unit: running - cream filling;
Freezing Unit has an addition of liquid spray).
7.Rotor with 3 sets of high-blower.
8.LG electrical components.
9.Emerson dry filter, pressure relay protection, the protection of high-temperature compressor temperature
control (temperature liquid spray for freezer).
10.Cooper piping tube + frozen oil + cooling of the refrigerant 404A +silver eletrode + Insulation.
Condensate water processor.Packing+carton box/wood box+certification
11.The doors of the cold room have safe lock which is help to open them from inside
The price is our weapon,quality is our life.To save the cost of investment and operating costs for our client,12
which is the goul that we always work for.For the better quality,We continue to innovate.

R22, R404a and other gas Condensing Unit For Cold Room Storage, Air Cooled

Feature of potato VENTTK refrigeration :
(1) Temperature range: -40ºC~+20ºC (-40ºF~+68ºF) are all available.
(2) Size: Customization.
(3) Functions: fresh-keeping, freezing, quick-freezing, fire-proof, explosion-proof, air-conditioning are all available.
(4) Fully automatic control system.



Box Type Compressor Condensing Unit Dimensions
Unit Model A B C D H H1 Installation bore
RFJ-BRA09M/60 RFJ-BRA06H/60 1050 750 700 850 1380 1500 4-θ13
RFJ-BRA12M/80 RFJ-BRA09H/80 1150 880 830 950 1500 1630 4-θ13
RFJ-BRA14M/100 RFJ-BRA10H/100 1370 880 830 1170 1600 1730 4-θ13
RFJ-BRA18M/120 RFJ-BRA12H/120 1450 950 900 1250 1600 1730 4-θ13
RFJ-BRA23M/160 RFJ-BRA15H/160 1610 950 900 1410 1600 1730 4-θ13
RFJ-BRA28M/200 RFJ-BRA20H/200 1710 950 900 1510 1650 1830 4-θ13
RFJ-BRA34M/240 RFJ-BRA25H/240 2120 1050 1050 1920 1780 1900 4-θ13
RFJ-BRA30H/270 2300 1050 1050 2100 1780 1900 4-θ13
RFJ-BRA44M/300 RFJ-BRA35H/300 2450 1050 1050 2250 1780 1900 4-θ13




BOX Type Compressor Condensing Unit
For box type condensing unit,we adopt high-performance compressor,optimized design condenser,reliable control components.overall design is reasonable,top discharge for condenser,which can reduce the interference to surrounding environment,access to the idea of environmentally design;metal structure for the overall housing,finished by anti-corrosion coating for the surface,with beautiful appearance,convenient in installation and stable for operation.
Condensing unit included:pressure controller,liquid receiver,filter drier,pressure gauge and solenoid valve etc high quality refrigeration parts.
Technical Parameters:medium & Low temperature unit parameters
Unit model compressor model Norminal refrigerating capacity
(KW)
Powerinput
(KW)
Power supply
(KW)
Fan of condenser Liquid receiver
(L)
Inlet
(mm)
Outlet
(mm)
Quantity Dimaeter of Vane
(mm)
Air Voume
(M3/H)
Moter power
(W)
RFJ-BRA09M/60 4TES-9Y 11.41 6.74 380v 3HP 50HZ 1 500 7000 1x450 8 25 19
RFJ-BRA12M/80 4PES-12Y 12.64 7.34 1 600 11000 1x780 10 25 19
RFJ-BRA14M/100 4NES-14Y 15.50 9.11 2 450 10000 2x250 12 28 22
RFJ-BRA18M/120 4HE-18Y 21.90 12.67 2 500 14000 2x450 15 28 22
RFJ-BRA23M/160 4GE-23Y 25.80 15.06 2 600 22000 2x780 20 28 22
RFJ-BRA28M/200 6HE-28Y 32.30 18.68 2 600 22000 2x780 25 28 22
RFJ-BRA34M/240 6GE-34Y 38.80 22.90 3 500 21000 3x450 35 38 25
RFJ-BRA44M/300 6FE-44Y 46.20 27.52 3 600 33000 3x780 45 42 28

Note: Nominal refrigerating capacity and power input are based on conditions of ambient temperature 32℃,evaporating temperature -23℃ and refrigerant R404A.
